Through holes open to the mold split on both ends, which changes venting and pin layout.
DFM
Open bores simplify fill and air escape compared with blind pockets.
Through holes often form with core pins spanning both mold halves at the parting line.
Pin alignment and flash control at the parting line matter for hole roundness.
Holes near thin walls need extra review so pins do not punch through during fill or ejection.
DFM
NetProto DFM review flags these geometry patterns before steel is ordered.

Hole callouts
Send these with CAD for DFM sign off.
Hole diameter and tolerance band on mating features only
Position relative to datums or centerlines
Parting line location through the hole axis if not obvious
